| Applications | : |
Hot and cold water systems, sea water (Ductile Iron),compressed air, superheated water, steam, superheated steam systems, non-acidic and nonflammable liquid fluids |
| Connection Size | : | Dn 15 … DN 300 |
| Connection Type | : | Flanged |
| Working Temperature | : | -10 ... +120 °C (16 Bar),200 °C (13 Bar), 250 °C (11 Bar), 300 °C (10 Bar) |
| Nominal Pressure | : | PN 16 , PN10 |
| Body Material | : | Cast Iron ,Ductile Iron or Cast Steel |
| Disc | : | DN 15-100, X20Cr13 - AISI420 Stainless Steel , DN 125-300, St 37 - Steel + Stainless Steel |
| Gasket | : | Klingerit |
| Seat | : | X5CrNi18 10 - AISI304 - Stainless Steel |
| Packing | : | Graphite |
| Stem | : | X20Cr13 - AISI420 - Stainless Steel |
| Handwheel | : | GG 25 - EN GJL 250 Cast Iron or GS-C 25 - GP240GH - Cast Steel |
| Packing Gland | : | CuZn40Pb2 - CW617N - Forced Brass |
