| Applications | : |
Hot and cold water systems, sea water (Ductile Iron),compressed air, superheated water, steam, superheated steam systems, non-acidic and nonflammable liquid fluids |
| Connection Size | : | Dn 15 … DN 300 |
| Connection Type | : | Flanged |
| Working Temperature | : | .-20 ... +400 °C (16 Bar) |
| Nominal Pressure | : | PN 16 |
| Body Material | : | Cast Steel |
| Disc | : | X5CrNi18 10 - AISI304 - Stainless Steel |
| Bellow | : | X5CrNi18 10 - AISI304 - Stainless Steel |
| Gasket | : | Flexible Graphite Gasket + Stainless Steel |
| Packing | : | Flexible Graphite Gasket |
| Stem | : | X5CrNi18 10 - AISI304 - Stainless Steel |
| Handwheel | : | St37 - Steel |
| Packing Gland | : | CuZn40Pb2 - CW617N - Forced Brass |
